Not so smooth criminals: how to use maths to catch a serial killer

The year is 1888, and the infamous serial killer Jack the Ripper is haunting the streets of Whitechapel. As a detective in Victorian London, your mission is to track down this notorious criminal – but you have a problem. The only information that you have to go on is the map below, which shows the locations of crimes attributed to Jack. Based on this information alone, where on earth should you start looking?

The fact that Jack the Ripper was never caught suggests that the real Victorian detectives didn’t know the answer to this question any more than you do, and modern detectives are faced with the same problem when they are trying to track down serial offenders. Fortunately for us, there is a fascinating way in which we can apply maths to help us to catch these criminals – a technique known as geospatial profiling.

Geospatial profiling is the use of statistics to find patterns in the geographical locations of certain events. If we know the locations of the crimes committed by a serial offender, we can use geospatial profiling to work out their likely base location, or anchor point. This may be their home, place of work, or any other location of importance to them – meaning it’s a good place to start looking for clues!

Perhaps the simplest approach is to find the centre of minimum distance to the crime locations. That is, find the place which gives the overall shortest distance for the criminal to travel to commit their crimes. However, there are a couple of problems with this approach. Firstly, it doesn’t tend to consider criminal psychology and other important factors. For example, it might not be very sensible to assume that a criminal will commit crimes as close to home as they can! In fact, it is often the case that an offender will only commit crimes outside of a buffer zone around their base location. Secondly, this technique will provide us with a single point location, which is highly unlikely to exactly match the true anchor point. We would prefer to end up with a distribution of possible locations which we can use to identify the areas that have the highest probability of containing the anchor point, and are therefore the best places to search.

With this in mind, let’s call the anchor point of the criminal z. Our aim is then to find a probability distribution for z, which takes into account the locations of the crime scenes, so that we can work out where our criminal is most likely to be. In order to do this, we will need two things.

A prior distribution for z. This is just a function which defines our best guess at what z might be, before we have used any of our information about the crime locations. The prior distribution is usually based off data from previous offenders whose location was successfully determined, but it’s usually not hugely important if we’re a bit wrong – this just gives us a place to start.
A probability density function (PDF) for the locations of the crime sites. This is a function which describes how the criminal chooses the crime site, and therefore how the criminal is influenced by z. If we have a number of crimes committed at known locations, then the PDF describes the probability that a criminal with anchor point z commits crimes at these locations. Working out what we should choose for this is a little trickier…

We’ll see why we need these in a minute, but first, how do we choose our PDF? The answer is that it depends on the type of criminal, because different criminals behave in different ways. There are two main categories of offenders – resident offenders and non-resident offenders.

Resident offenders are those who commit crimes near to their anchor point, so their criminal region (the zone in which they commit crimes) and anchor region (a zone around their anchor point where they are often likely to be) largely overlap, as shown in the diagram:

If we think that we may have this type of criminal, then we can use the famous normal distribution for our density function. Because we’re working in two dimensions, it looks like a little hill, with the peak at the anchor point:

Alternatively, if we think the criminal has a buffer zone, meaning that they only commit crimes at least a certain distance from home, then we can adjust our distribution slightly to reflect this. In this case, we use something that looks like a hollowed-out hill, where the most likely region is in a ring around the centre as shown below:

The second type of offenders are non-resident offenders. They commit crimes relatively far from their anchor point, so that their criminal region and anchor region do not overlap, as shown in the diagram:

If we think that we have this type of criminal, then for our PDF we can pick something that looks a little like the normal distribution used above, but shifted away from the centre:

Now, the million-dollar question is which model should we pick? Determining between resident and non-resident offenders in advance is often difficult. Some information can be made deduced from the geography of the region, but often assumptions are made based on the crime itself – for example more complex/clever crimes have a higher likelihood of being committed by non-residents.

Once we’ve decided on our type of offender, selected the prior distribution (1) and the PDF (2), how do we actually use the model to help us to find our criminal? This is where the mathematical magic happens in the form of Bayesian statistics (named after statistician and philosopher Thomas Bayes).

Bayes’ theorem tells us that if we multiply together our prior distribution and our PDF, then we’ll end up with a new probability distribution for the anchor point z, which now takes into account the locations of the crime scenes! We call this the posterior distribution, and it tells us the most likely locations for the criminal’s anchor point given the locations of the crime scenes, and therefore the best places to begin our search.

This fascinating technique is actually used today by police detectives when trying to locate serial offenders. They implement the same steps described above using an extremely sophisticated computer algorithm called Rigel, which has a very high accuracy of correctly locating criminals.

So, what about Jack?

If we apply this geospatial profiling technique to the locations of the crimes attributed to Jack the Ripper, then we can predict that it is most likely that his base location was in a road called Flower and Deane Street. This is marked on the map below, along with the five crime locations used to work it out.

Unfortunately, we’re a little too late to know whether this prediction is accurate, because Flower and Deane street no longer exists, so any evidence is certainly long gone! However, if the detectives in Victorian London had known about geospatial profiling and the mathematics behind catching criminals, then it’s possible that the most infamous serial killer in British history might never have become quite so famous…

Francesca Lovell-Read

December 6, 2018 1

SJC Inspire: how to design a successful video game

Very excited to announce the launch of the SJC Inspire digital magazine this week – a project I’ve been working on for the past few months in my role as Access and Outreach Associate for STEM at St John’s College, Oxford.

The first issues is ‘how to design a successful video game’ and features articles by researchers at St John’s, video interviews with students at the college, and practice puzzles set (and solved) by real Oxford tutors (myself included). I’ve highlighted some of my favourites below, but be sure to check out the full contents of the issue on the website here.

Maths in video games

My former tutorial partner, James Hyde, now works for Creative Assembly developing hit titles such as Halo Wars and Halo Wars 2. Here he explains how maths has helped him to land his dream job…

Fun and games at the circus

Try out this maths puzzle set by St John’s maths tutor Dr David Seifert. If you send your answers in to inspire@sjc.ox.ac.uk you might even win a goodie bag!

How to earn billions by giving something away for free

St John’s Economics tutor Dr Kate Doornik explains the pricing strategy behind the incredibly successful ‘Fortnite: Battle Royale’. Originally given away for free, it is expected to make over $3 billion in sales in 2018…

November 21, 2018 0

Goldbach’s Conjecture: easy but hard

Often in Mathematics problems that are easy to state turn out to be extremely difficult to solve. Two hundred and seventy-five years ago, Goldbach wrote a letter to the famous Swiss mathematician Leonhard Euler in which he wrote the simple statement:

“Every even integer greater than 2 can be expressed as the sum of two primes.”

Just in case you are not up to speed with your maths (and let’s face it why would you be if you’re not a mathematician), let’s break this statement down. The even integers are the numbers divisible by two: 2, 4, 6, 8, …, 256, … and so on. The prime numbers are the ones that can only be obtained by multiplying one by themselves. For example, 3 and 5 are prime numbers because 3=1×3 and 5=1×5 and they have no other representations as a product of two numbers. However, 6 for instance is not prime because 6=1×6=2×3. In fact, all even integers, greater than 2 that were mentioned above, are not primes because they are all divisible by 2 and therefore can be represented as a product of two numbers in at least two ways: 4=1×4=2×2, 6=1×6=2×3, 8=1×8=2×4 etc.

And so, to Goldbach’s conjecture. It says that all even numbers: 4, 6, 8, 10, … can be written as a sum of two primes. Let’s see a couple of examples:

4=2+2

6=3+3

8=3+5

10=3+7

12=5+7

….

A nice way to represent the conjecture visually is through a “pyramid” and because we all love pretty pictures let’s see how this magic happens.

First, we write all of the prime numbers on two of the sides of a triangle as below: 2, 3, 5, 7 etc. We then draw a line leaving each prime number which is parallel to the opposite side of the triangle (stick with me), and finally at the points of intersection of these lines, we write the sum of the numbers. It sounds more complicated than it is as you’ll see with the following example. In the picture below, take the blue line coming out of the number 7 on the left and the red line coming out from the number 11 on the right. They intersect at 18 because 11+7=18. This means that the even integer 18 can be represented as a sum of the two prime numbers 11 and 7. If you look at the intersections of all of the red and blue lines in the pyramid, you’ll see that we actually get all of the even numbers. In other words, any even integer can be written as the sum of two prime numbers, and we can see what those two numbers are by finding the corresponding intersection on our diagram. This is Goldbach’s Conjecture.

It is not very difficult to show that a small even number greater than 2 is the sum of two prime numbers – either by finding the corresponding point on the picture or by trying all of the possibilities. Let’s take 96. We start by checking the smallest prime number 3. 96=3+93, but 93 is not a prime, because 93=1×93=3×31. We continue with the next prime – 5. 96=5+91, which again doesn’t work because 91=1×91=7×13. Next, we try with 7: 96=7+89. Since 89 is a prime, we have obtained a representation of the number 96 as a sum of two primes.

We were able to quickly check whether 96 satisfies Goldbach’s conjecture because the number is relatively small. It becomes much harder to make these checks for larger numbers. It’s been verified with the use of a computer that the conjecture is true for numbers as big as 4×10¹⁸ and this is why the conjecture is believed to be true, but we do not yet have a formal mathematical proof. And being mathematicians, we cannot say something is true until we can prove it.

There have of course been many efforts over the last 275 years to try to prove the conjecture, most of which followed one of two routes. Either by proving that all even integers can be represented as a sum of some number of primes – as a sum of 6 primes (1995, Ramare) and as a sum of 4 primes (Herald Helfgott) – or by proving that almost all even integers can be written as a sum of 2 primes. But, as of yet, the secret formula required to unlock the proof of Goldbach’s Conjecture remains elusive.

You may be wondering why on earth mathematicians are spending their time and effort to prove this seemingly random result about prime numbers? Is it really that important? Whilst you may have a valid point about the applications of this particular conjecture, the value in proving such a result is not in the statement itself, but rather in the new methods, theories and techniques that will need to be developed to solve the problem. So, in 20, 10 or even 2 years from now when you hear that Goldbach’s conjecture has been proved, you should be happy not because we now know for sure that it’s true, but rather because some incredible new area of mathematics has been developed in the process. And who knows, this new area of maths may even pose a new, even more complicated conjecture that will occupy mathematicians for the next 275 years…

Mariya Delyakova

November 15, 2018 0

JFM China Symposia: Beijing

Video highlights from the third and final stop of the JFM China Symposia in Beijing. We were hosted by Tsinghua University with further speakers from Peking University, Xidian University, Beihang University and the Chinese Academy of Sciences.

Ke-Qing Xia describes how water in the ocean travels the entire globe over the course of 1000 years

Colm Caulfield explains how to the shape of a hanging chain is related to turbulence

Charles Meneveau discusses wind energy and its future as the current cheapest form of energy in the US

Photo: Christian Steiness

November 12, 2018 0

JFM China Symposia: Hangzhou

I’m in China this week documenting the JFM Symposia ‘from fundamentals to applied fluid mechanics’ in the three cities of Shenzhen, Hangzhou and Beijing. Check out the CUP website for daily blog entries as well as some of my favourite video highlights from the scientific talks in Hangzhou below.

Detlef Lohse describes how a good scientist must be patient like a good bird-watcher as demonstrated by his experiments with exploding ice droplets

Hang Ding discusses falling droplets and shows a video of one hitting a mosquito

Quan Zhou presents some amazing visuals of Rayleigh-Taylor turbulence

November 9, 2018 0

Tom Rocks Maths S02 E01

Tom Rocks Maths is back on Oxide – Oxford University’s student radio station – for a second season. The old favourites return with the weekly puzzle, Funbers and Equations Stripped. Plus, the new Millennium Problems segment where I tell you everything that you need to know about the seven greatest unsolved problems in the world of maths, each worth a cool $1 million. And not to forget the usual selection of awesome music from artists such as Rise Against, Panic at the Disco, Thirty Seconds to Mars – and for one week only – Taylor Swift. This is maths, but not as you know it…

November 8, 2018 0

JFM China Symposia: Shenzhen

I’m in China this week documenting the JFM Symposia ‘from fundamentals to applied fluid mechanics’ in the three cities of Shenzhen, Hangzhou and Beijing. I’ll be writing daily blog entries on the CUP website as well as posting some of my favourite video highlights from the scientific talks, starting with the first symposium in Shenzhen.

Detlef Lohse explains the evaporation of a drop of Ouzo (a traditional Greek alcohol)

Colm Caulfield describes the two types of mixing present in the ocean (including a fantastic visualisation of KH instability)

Anderson Shum demonstrates how a fluid can behave as a ‘dancing ribbon’

November 7, 2018 0

Take me to your chalkboard

Is alien maths different from ours? And if it is, will they be able to understand the messages that we are sending into space? My summer intern Joe Double speaks to philosopher Professor Adrian Moore from BBC Radio 4’s ‘a history of the infinite’ to find out…

October 31, 2018 0

Complex Numbers – they don’t have to be complex!

The idea of complex numbers stems from a question that bugged mathematicians for thousands of years: what is the square root of -1? That is, which number do you multiply by itself to get -1?

Such a simple question has blossomed into a vast mathematical theory, for the simple reason that the answer isn’t real! It can’t be 1, as 1 * 1 = 1; it can’t be -1, as -1 * -1 = 1; whichever number you multiply by itself, you can’t get a negative number. Up until the 16th century, almost everyone ignored this issue; perhaps they were afraid of the implications it could bring. But then, gradually, people began to realise that there was a whole new world of mathematics waiting to be discovered if they faced up to the question.

In order to explain this apparent gap in maths, the idea of an ‘imaginary’ number was introduced. The prolific Swiss mathematician Leonhard Euler first used the letter i to represent the square root of -1, and as with most of his ideas, it stuck. Now i isn’t something that you’ll see in everyday life in relation to physical quantities, such as money. If you’re lucky enough to have money in your bank account, then you’ll see a positive number on your bank statement. If, as is the case for most students, you currently owe money to the bank (for example, if you have an overdraft), then your statement will display a negative number. However, because i is an ‘imaginary’ unit, it is neither ‘positive’ nor ‘negative’ in this sense, and so it won’t crop up in these situations.

Helpfully, you can add, subtract, multiply and divide using i in the same way as with any other numbers. By doing so, we expand the idea of imaginary numbers to the idea of complex numbers.

Take two real numbers a and b – these are the type that we’re used to dealing with.

They could be positive, negative, whole numbers, fractions, whatever.

A complex number is then formed by taking the number a + b * i. Let’s call this number z.

We say that a is the real part of z, and b is the imaginary part of z.

Any number that you can make in this way is a complex number.

For example, let a = -3 and b = 2; then -3 + 2*i, which we write as -3 + 2i, is a complex number.

As we saw before, complex numbers don’t actually pop up in ‘real-life’ situations. So why do we care about them? The reason is that complex numbers have some very neat properties that allow them to be used in all sorts of mathematical contexts. So even though you may not see the number i in everyday life, it’s very likely that there are complex numbers involved behind the scenes wherever you look. Let’s have a quick glance at some of these properties.

The key observation is that the square of i is -1, that is, i * i = -1.

We can use this fact to multiply complex numbers together.

Let’s look at a concrete example: multiply 2 + 2i by 4 – 3i.

We use the grid method for multiplying out brackets:

	4	-3i
2	2 * 4 = 8	2 * -3i = -6i
+2i	4 * 2i = 8i	2i * -3i = -6 * i * i = -6 * -1 = 6

Adding the results together, we get (2 + 2i)(4 – 3i) = 8 + 6 – 6i + 8i = 14 + 2i.

Therefore, multiplying two complex numbers has given us another complex number!

This is true in general, and it turns out to be very handy. In fact, Carl Friedrich Gauss proved a very famous result – known as the Fundamental Theorem of Algebra because it’s so important – that effectively tells us that the solutions to all equations can be written as complex numbers. This is extremely useful because we know that we don’t have to go any ‘deeper’ into numbers; once you’ve got your head around complex numbers, you can proudly declare that you’ve mastered them all!

Because of this fundamental theorem, our little friend i pops up all over the place in physics, engineering, computer science, and of course, in all sorts of areas of maths. While it may only be imaginary, its applications can be very real, from air traffic control, to animating characters in films. It plays a really important role in much of theoretical mathematics, which in turn is used in almost every scientific discipline. And to think, all of this stemmed from an innocent-looking question about -1; what were they so scared of?!

Kai Laddiman

October 24, 2018 0
